1:2 HDMI/DVI-D to HDMI/DVI-D

$5,000.00

This Virtual Package includes:

PCB Gerber Files
BOM
Source Codes
Compliant FW Supplied
Packaging design files
Enclosure design files

Qty
SKU: REV-12NORM-PCB-SC Category:

Product Description

1:2 SPLITTER HDMI/DVI-D to HDMI/DVI-D

Specifications and Capabilities:

AutoMix EDID feature will create a custom EDID by mixing both sink EDID connected to the splitter output ports.
DVI Specification 1.0 Compliant
HDMI Specification 1.4a Compliant
Splitter 4K UHD handles all video formats down to SD (480p) and all the way up to UHD (2160p)
Integrated automatic EDID processing
Wide Frequency Range: 25MHz – 340MHz (beyond 4K spec)
Supports 12-bit Deep Full HD, Full 3D and 4K2K video.
Supports Standard Audio, DSD Audio and HD (HBR) Audio
Supports 1 DVI/HDMI input port and 2 DVI/HDMI output ports
Supports conversion of HDMI signaling to DVI signaling
Up to 4K30 4:4:4 or 4K60 4:2:0.
Scalable to make more than 4 output ports
Supports 2D and 3D video signals in NTSC 480i/p, PAL 576i/p, HDTV 720p/1080i/1080p/1440p/2160p
Size : 65 * 49 * 39 (mm)
Custom and manual EDID utility.
Reset switch so you will never have to unplug and replug HDMI cable again, just press the reset button and HPD events is reinitialized.
