1:2 HDMI/DVI-D to HDMI/DVI-D PRO

$10,000.00

This Virtual Package includes:[list type=”iconrightopen” style=”themed”]

  • PCB Gerber Files
  • BOM
  • Source Codes
  • Compliant FW Supplied
  • Packaging design files
  • Enclosure design files
Qty
SKU: REV-12PRO-PCB-SC Category:

Product Description

1:2 SPLITTER HDMI/DVI-D to HDMI/DVI-D PRO

Specifications and Capabilities:

  • 3 Ghz Repeater with 4K2K Super Resolution Engine (SRE)
  • Video Scaling and Audio Re-Timing
  • Independant Upscaling and Downscaling engine embedded with 3 modes set on-the-fly via slide switch.
  • 1080p24/25/30 to 4K24/25/30 or 4K24/25/30 to 1080p24/25/30, all others formats pass-through.
  • AutoMix EDID feature will create a custom EDID by mixing both sink EDID connected to the splitter output ports.
  • DVI Specification 1.0 Compliant
  • HDMI Specification 1.4a Compliant
  • Splitter 4K UHD handles all video formats down to SD (480p) and all the way up to UHD (2160p)
  • Integrated automatic EDID processing
  • Wide Frequency Range: 25MHz – 340MHz (beyond 4K spec)
  • Supports 12-bit Deep Full HD, Full 3D and 4K2K video.
  • Supports Standard Audio, DSD Audio and HD (HBR) Audio
  • Supports 1 DVI/HDMI input port and 2 DVI/HDMI output ports
  • Supports conversion of HDMI signaling to DVI signaling
  • Up to 4K30 4:4:4 or 4K60 4:2:0.
  • Scalable to make more than 4 output ports
  • Supports 2D and 3D video signals in NTSC 480i/p, PAL 576i/p, HDTV 720p/1080i/1080p/1440p/2160p
  • Size : 65 * 49 * 39 (mm)
  • 4K Image Enhancement mode with an easy one button control.
  • Improved EDID Management solution with either a Custom uploaded EDID, Self generated Automix EDID or a Fixed basic EDID.
  • Reset switch so you will never have to unplug and replug HDMI cable again, just press the reset button and HPD events is reinitialized.
