2x HDMI/DVI-D to VGA/RGBHV and YUV/Component with Optical 5.1 and Analog Stereo Sound rev.3

$30,000.00

This Virtual Package includes:

PCB Gerber Files
BOM
Source Codes
Compliant FW Supplied
Packaging design files
Enclosure design files

Qty
SKU: REV-THREE-PCB-SC Category:

Product Description

2x HDMI/DVI-D to VGA/RGBHV and YUV/Component with Optical 5.1 and Analog Stereo Sound rev.3

Specifications:

Input: 2 x HDMI v1.3 (DVI 1.0 compatible)
Switch: Auto / PortA / PortB
10-bit deep color HDMI native support
Output: VGA FEMALE output connector, 10 bit analog resolution.
Horizontal shift capability for RGB output mode
Enabled with a dip-switch, applied with push-buttons
Output sync polarity selector for RGB modes (dip switch)
Output format: Either RGB or YPbPr, dip-switch selectable
YPbPr requires VGA->3RCA breakout cable
All HD/SDTV formats from 1080p down to 480i, NTSC and PAL
Including 1080p @ 72Hz PAL and NTSC (for RGB output only)
Including 1080p @ 24Hz PAL and NTSC
11-bit 225MHz DAC processing (for true 10-bit analog output)
Two separate Internal EDID EEPROM with complete CEA861 extension block
Dip-switch selectable
One EDID supports all formats (by default, reprogrammable)
The other EDID is up to 1080i, and no 24Hz support (by default, reprogrammable)
Automatic Input Format Detection: Digital YCbCr and RGB
Full BTB and WTW support in YPbPb output
Automatically switches color-spaces for both HDTV and SDTV
Precise black levels – no black crush in any standard mode
Dual purpose audio output connector*
SPDIF digital output for 5.1 Dolby/DTS
Analog L/R 2-channel stereo
Industry-Standard Compliance
HDMI 1.3
EIA/CEA-861D
DVI 1.0
Digital Video Input / Output
Dual integrated HDMI 1.3 cores
Supports DTV resolutions up to 1080p @ 72Hz or 720p/1080i @ 120Hz with 36-bit color depth.
Flexible digital video interface:- 24/30/36-bit RGB/YCbCr 4:4:4- 16/20/24-bit YCbCr 4:2:2- 8/10/12-bit YCbCr 4:2:2 (ITU-R BT.656)
Integrated RGB Color Space Converter for both RGB-to-YCbCr and YCbCr-to-RGB (both 601 and 709) with true 12-bit accurate data using 14-bit processing
4:2:2 <> 4:4:4 converter with 12-bit accurate data using 14-bit processing
Digital Audio Output
Industry-standard S/PDIF output
Supports 2-channel 32-192kHz stereo audio
Supports IEC60958 2-channel PCM
Capable of passing IEC61937 compressed audio (5.1 Dolby® Digital, DTS, etc.)

*No end-user access to decrypted analog video.
