2017 ULTRA FAST INTEGRAL EDITION NOW SHIPPING! COMPARE BT SPEED: NEW INTEGRAL vs PREVIOUS ONE
UHD Splitter, with HDR/DV/SDR control & HDCP Doctor
Final batch of HDfury Integral is limited to 4K60 4:2:0 300MHz 10.2Gbps.
HDfury Integral is capable of connecting any HDCP revision sources devices to any HDCP revision sink devices. GUARANTEED!
If you ever saw the following statement: “this TV does not support HDCP 2.2. Make sure you have HDCP 2.2 capable TV” or a similar HDCP error message, make sure you never see it again with HDfury Integral! Featuring 2 inputs and 2 outputs, HDfury Integral can act as a Splitter, Infoframe and HDR metadata Injector and Extractor, HDCP Doctor, CEC Commander, Audio extractor, Audio replacement, HDMI Doctor, Matrix, EDID management and more… Discover the tomorrow’s hardware today!
HDfury Integral Key Features
Unique HDCP Doctor
Providing a total of 6 HDCP 1.4 and 2.2 engines for decryption/encryption. HDfury Integral offers a total HDCP workaround solution including HDCP 2.2 > HDCP 1.4 and HDCP 1.4 > HDCP 2.2 both ways conversion within the same unit.
It is capable of connecting any HDCP1.x or HDCP2.x source devices to any HDCP1.x or HDCP 2.x sink devices.
Each RX block decrypts the input first whether its 1.x or 2.x. Then each output port can individually encrypts it to 1.4(both) or 2.2(only top port) or not encrypt it at all if it was not encrypted initially.
Dual conversion can be operated on both channels simultaneously.*
Display HDCP 2.2 Content with Non-HDCP2.2 Compliant Devices
HDCP 2.2 is the new copy-protection scheme for 4K UHD content. Not only it is not backward compatible but many recent 4K devices don’t even support it.
Source devices, including media servers and head-ends like Netflix, will encode their 4K content with this new scheme. TVs must be HDCP 2.2-enabled to play it, and everything in the video chain including switches and receivers must be compliant as well, or the display will go dark and/or display a HDCP error message.
Bad news for consumers who have purchased expensive, high-bandwidth, processor-rich switchers, receivers and displays to accommodate 4K. While the newer products may support the bandwidth needs of 4K, they won’t play copy-protected works until Integral is an active part of the setup.
2×2 Splitter up to 4K60 4:2:0 300MHz 10.2Gbps
Splitting any signal up to 4K60 4:2:0 300MHz. Thanx to IR/BT/USB or push button, you can easily switch between 2 inputs that will be replicated to 2 outputs. HDCP conversion can be configured and applied on the fly in order to always output the type of HDCP signal encryption that your display or sink device is expecting.
HDR and Infoframe Metadata Live Injector and Extractor
The Integral is capable of injecting and extracting live Infoframe and HDR metadata at any resolution and in real time.
Using latest firmware you can turn ON/OFF the HDR MODE of your HDR display at will from push buttons, APP, IR or USB GUI PC windows software. See it in video: here.
A further software solution for a complete real time handling of infoframe and HDR metadata is now available: here from our exclusive licensed partner AV TOP.
HDMI Audio Extracting
HDfury Integral can extract HDMI audio up to 5.1 and pass-thru any sound format including Atmos via HDMI. It have a simultaneous output of analog L/R stereo and up to 5.1 optical S/PDIF via 3.5mm combo jack connector.
External Audio Replacing
Mini jack input connector (or Mic/Line IN) option is available to replace the audio in any HDMI/DVI-D stream up to 4K60 4:2:0 300MHz 10.2Gbps.
Audio replacing only work on one channel, the secondary channel is a direct path from HDMI to HDMI.
Useful in presentation areas or for simply streaming your phone/tablet music to your HDMI amp.
Advanced EDID Management
The most advanced EDID Management solution we ever done is now available from the Integral with either:
A Selected EDID bank, a Custom uploaded EDID, a Self generated Automix EDID or a Fixed basic EDID.
Sniff EDID from connected sink devices, Save, Edit, Load any custom EDID table at anytime.
Select and pick any EDID of your choice from a preloaded list of 25 EDID tables, it loads and reset HPD to present your chosen one automatically.
AutoMix EDID feature will create a custom EDID by mixing both sink EDID connected to the splitter output ports.
Mixing rules in AutoMix mode can be selected through 4 different algorithms.
Some EDID flags can be forced in Automix such as: Stereo/5.1/Full/YCbCr/BT2020/HDR/DV/3D.
HDMI/CEC Total Commander
HDfury Integral offers an unique CEC commands manager, with CEC compatible equipment.
CEC commands allow a HDMI source to send instructions and operate check on connected HDMI devices.
Using USB, IR, Push buttons or the Integral’s Android/Apple APP for smartphone/tablet, user can configure custom CEC commands and send them LIVE or based on trigger event.
4K Integral Total Control APP is available on Google Market for mobile and tablet running Android and on the AppStore for iOS.
You can control HDfury Integral using your mobile phone or tablet via an auto-pairing bluetooth connection.
USB GUI Utility via Windows PC, IR control and various physical buttons for configurations are also available.
Thanks to the community, IR pronto code list was added to iRule and Logitech Harmony for even easier and seamless integration
Having issue with AVR or display connected at your HTPC output, like standby mode resume issue or such ?
Integral now feature an unique and exclusive HTPC mode where anything that happen at the output is never reported to the source device.
This currently goes beyond what EDID detective and Dr.HDMI alike can offer and represent the ultimate HTPC issue solver.
2×2 Matrix up to 4K30 4:4:4 300MHz or 4K60 4:2:0 300MHz
Matrix solution is available for HDMI stream up to 4K30 4:4:4 300MHz 10.2Gbps or 4K60 4:2:0 300MHz 10.2Gbps
* In Matrix mode only one HDCP 2.2 input is allowed, the other must be HDCP1.4 or DVI-D/HDCP 0.0
